NEMO® SY With Bearing Housing and Free Shaft End
Used worldwide for demanding applications in every branch of industry
The NEMO® SY Progressing Cavity Pump is used for demanding applications in every industrial market worldwide. Bearing housing design with free input shaft pump can be run with any type of drive, such as servo motors, diesel motors or hydraulic drives.
This pump can also handle high-pressure applications. Four rotor/stator geometries are available, to customize the pump for your application. The NEMO® SY is suitable for all industrial markets where low- to mid-viscosity and/or shear-sensitive, abrasive or adhesive substances must be safely and gently handled.
Features of the NEMO® SY Progressing Cavity Pump
- continuous low-pulsation conveyance unaffected by fluctuations in pressure and viscosity
- capacity in proportion to rotation speed with high metering precision over a wide speed range
- high pressure capability without valves
- mechanical seal is located at the front of the product flow, making flushing unnecessary in many applications.
- easy stator replacement
The NEMO® SY Progressing Cavity Pump offers you:
- conveying pressure up to 1000 psi
- gentle product conveyance
- pump connections in accordance with national and international standards, as well as in specially designed models
- easy serviceability
Advantages of the NEMO® SY Progressing Cavity Pump
- variable modular system
- various rotor/stator geometries in a broad range of materials
- the right joint for any application
- standard mechanical seal, other seals optional
Everything from a single supplier
For the various applications in your processes, NEMO® Progressing Cavity Pumps and NETZSCH TORNADO® Rotary Lobe Pumps are available from a single source!
Take advantage of our decades of experience and expertise in positive displacement pump manufacture.
Technique

- Variable, modular construction system
- Various rotor/stator geometries and a wide range of materials
- The right joint for every application
- Mechanical seal as standard, other seals optional
- Gentle product conveyance
| Name | Pressure max. (bar) | Capacity min. (m³/h) | Capacity max. (m³/h) | Speed (rpm) |
|---|---|---|---|---|
| NM003 SY | 72 | up to | 0.003 | 1,000 |
| NM005 SY | 72 | up to | 0.015 | 1,000 |
| NM008 SY | 72 | up to | 0.1 | 1,000 |
| NM011 SY | 72 | up to | 0.2 | 1,000 |
| NM015 SY | 72 | up to | 2.5 | 800 |
| NM021 SY | 72 | up to | 3 | 800 |
| NM031 SY | 72 | up to | 5.4 | 600 |
| NM038 SY | 72 | up to | 18 | 600 |
| NM045 SY | 72 | up to | 20 | 550 |
| NM053 SY | 72 | up to | 31.5 | 550 |
| NM063 SY | 72 | up to | 38 | 550 |
| NM076 SY | 72 | 4 | 60 | 550 |
| NM090 SY | 60 | 5 | 88 | 450 |
| NM105 SY | 48 | 6 | 133 | 350 |
| NM125 SY | 36 | 20 | 130 | 350 |
| NM148 SY | 24 | 28 | 350 | 250 |
Additional sizes and technical data on request.

Worldwide service and support for your pump and system
Our service and support do not end with the purchase. From consultation, spare parts and maintenance to the repair and modernization of your pump - we support you right from the start.
By use of our worldwide service network, we are ready for you around the clock in case of an emergency.
Literature
- NEMO® Progressing Cavity PumpsBrochure

- MultiProtector: The Monitoring and Protection UnitBrochure

- Lithium Battery ManufacturingBrochure

- Wastewater TreatmentBrochure

- aBP-Module®Brochure

- Sludge Cake Conveying SystemsBrochure

- Independent ControlsBrochure

- Customer Service/AftermarketBrochure

- Product PortfolioBrochure

Applications NEMO® SY with bearing housing
FAQ progressing cavity pumps
Progressing cavity pumps are particularly suitable for pumping highly viscous, abrasive, solid-laden or shear-sensitive media. Typical applications include the chemical, food, environmental, paper and building materials industries, as well as the oil and gas sector.
NEMO® progressing cavity pumps from NETZSCH Pumps & Systems are characterised by gentle, low-pulsation pumping, high dosing accuracy and a wide range of applications. They enable a constant delivery rate even with changing pressures and media compositions.
Progressing cavity pumps can be used to convey low-viscosity to highly viscous media, including slurries, suspensions, pastes, media with a high solids content, and sensitive or gas-laden liquids.
Yes, progressing-cavity pumps are self-priming and exhibit excellent suction performance. This makes them ideal for applications with changing fill levels or difficult suction conditions.
NEMO® progressing cavity pumps are available in numerous designs, including block, hopper and hygienic versions. In addition, various materials, seal variants, and rotor-stator combinations are available to optimally adapt the pump to the respective application.
Maintenance requirements are low and predictable. Wear parts such as the rotor and stator can be easily replaced. Maintenance-friendly designs enable short downtimes and high plant availability.
The service life depends on factors such as the medium, speed, pressure and choice of materials. Professional design and the use of original spare parts ensure a long service life and economical operation.
All relevant original spare parts are available for progressing cavity pumps from NETZSCH Pumps & Systems, including rotors, stators, seals, joint parts and other wear-related components. The spare parts are precisely matched to the pump design and ensure high operational reliability.
The correct spare part can be identified by the machine number, serial number, or item number. Spare parts lists, sectional drawings and the operating and maintenance instructions also provide support. Alternatively, the NETZSCH Pumps & Systems service team can provide expert advice on selecting the right original spare part.
Yes, specialised hygienic versions of NEMO® progressing cavity pumps meet the stringent requirements of the food and pharmaceutical industries. They are easy to clean and can be designed to meet current hygiene standards.
The experts at NETZSCH Pumps & Systems will assist you in the design, selection and integration of the right progressing cavity pump – tailored to your specific pumping tasks and process requirements.
